Overview:
Customized Compression Rubber Mold Tooling for Silicone Products is precision-engineered tooling designed for high-volume production of silicone components. These molds are crafted using advanced CNC machining and EDM (Electrical Discharge Machining) processes to ensure micron-level accuracy. Primary materials include premium-grade tool steels like P20, H13, or 7075 aluminum alloys, selected for their durability, heat resistance, and ability to withstand repeated compression cycles. Our molds feature a proprietary non-stick surface coating, such as PTFE or nickel-PTFE hybrid, to enhance release performance, reduce flash, and extend mold lifespan.
As a certified OEM manufacturer with full in-house capabilities, we offer seamless one-stop service from design consultation to mold fabrication and post-production support. Our tooling guarantees fast turnaround times, consistent part quality, and optimized production efficiency for silicone rubber parts across medical, automotive, and consumer industries.
Characteristics:
| Specification Category | Details |
| Material Options | – Tool Steel: P20 (HRC 30-32), H13 (HRC 45-48) – Aluminum Alloy: 7075-T6 (Hardness: 150 HB) – Optional: Stainless Steel (420/304) |
| Surface Coating | – Non-Stick Coating: PTFE (5-10μm) or Nickel-PTFE Hybrid – Benefits: Anti-adhesion, reduced flash, extended mold life (>500,000 cycles) |
| Manufacturing Process | – CNC Machining (±0.01mm tolerance) – EDM (Electrical Discharge Machining) for complex geometries – Precision Grinding & Polishing (Ra ≤0.4μm) |
| Mold Lifespan | – Steel Molds: 500,000+ cycles – Aluminum Molds: 50,000-100,000 cycles (ideal for prototyping/low-volume) |
| Lead Time | – Standard: 10-15 business days – Rush Service: 5-7 business days (additional cost applies) |
| Tolerances | – Dimensional Accuracy: ±0.02mm – Surface Finish: Up to SPI-A1 (Mirror Finish) |
| Compatibility | – Optimized for silicone rubber (Shore A 10-80), LSR, HTV, and RTV materials |
| Additional Services | – OEM/ODM Support: DFM analysis, 3D prototyping – One-Stop Service: Mold design, trial testing, mass production support |
Surface Coating Options：
- PTFE (Polytetrafluoroethylene) Coating
– A non-stick, low-friction coating ideal for preventing silicone adhesion and minimizing flash formation.
– Enhances mold release efficiency and reduces downtime for cleaning.
- Nickel-PTFE Hybrid Coating
– Combines electroless nickel plating with embedded PTFE particles for superior wear resistance and non-stick properties.
– Extends mold lifespan in high-volume production (500,000+ cycles).
- Hard Chrome Plating
– Provides exceptional hardness (HRC 65-70) and corrosion resistance for molds exposed to abrasive silicones or harsh curing environments.
– Maintains dimensional stability under high-temperature compression (up to 250°C/482°F).
- Titanium Nitride (TiN) Coating
– A PVD (Physical Vapor Deposition) coating offering extreme surface hardness and thermal resistance.
– Reduces wear in high-pressure molding applications and improves resistance to chemical degradation.
Quality Assurance:
Our quality assurance framework integrates full-spectrum protocols, including ISO 9001:2015 and IATF 16949 certifications, to ensure compliance with medical, automotive, and industrial standards. Rigorous material inspection utilizes spectrometers (for alloy verification) and hardness testers (Rockwell C scale) to validate tool steel (P20/H13) or aluminum (7075-T6) specifications. Dimensional accuracy is guaranteed via CMM (Coordinate Measuring Machines) with ±0.005mm precision and surface roughness testers (Ra ≤0.4μm). Coating integrity is assessed through XRF (X-ray fluorescence) for PTFE/Ni-PTFE thickness and adhesion tests per ASTM D3359. For durability, molds undergo thermal cycling trials (up to 250°C) and pressure simulation (200+ tons) to validate cycle life (500K+ for steel molds). Our in-house NDT (non-destructive testing) and 3D scanning ensure defect-free tooling, while certified material traceability and DFM (Design for Manufacturability) reports are provided. All processes align with FDA 21 CFR Part 820 for medical-grade silicone applications.
Factory Show:
Our advanced manufacturing facility is equipped with cutting-edge technologies, including CNC machining, Mirror EDM, EDM, and Slow-Speed Wire Cut (WC), guaranteeing exceptional precision in mold production. We operate a comprehensive fleet of 15 rubber compression molding machines and 2 LSR injection molding machines, enabling high-volume production while maintaining superior efficiency.
To maintain the highest quality standards, we employ sophisticated instruments such as 3D projectors, sealing testers, durometers, and elasticity measurement devices, all of which are carefully managed by our certified quality control team. Our operations fully adhere to ISO 9001 and IATF 16949 standards, ensuring consistent quality and reliability throughout every stage of production.
Furthermore, we leverage automated systems, including AutoDryers, high-speed doming machines, and die-cutting machines, to further enhance production accuracy and operational efficiency. This integration of advanced technology underscores our commitment to delivering superior products with outstanding performance and reliability.
